HALTER LOADASSISTANT
With automation, productivity ratios will be higher, work will be more efficient, and processes will be more cost-effective. Work will be more predictable and plannable.
Automatic servicing of CNC machines is one of the most important tasks, which all companies should invest in who want to, in addition to increasing productivity, keep costs low.
- 1 - Prepairing new series
- 2 - Halter Smart Control
- 3 - Floor scanner
- 4 - Quality and reliable technology
- 5 - Rotary load system
- 6 - Easy to move from one CNC machine to another
- 7 - FANUC 6-axis robot
- 8 - Universal gripping system
- 9 - Automatic door opening
- 10 - Halter machine interface
HALTER LoadAssistant® is an easy-to-use, fast-to-program, and secure robotic systemdesigned to make work continuous, predictable, and more efficient by automatically servicing your CNC machine, reducing human labor costs and time.
The set-up time is less than 5 minutes, so skilled machine operators don’t have to spend their valuable time operating the machine.
The robot cell can be connected to any new or existing CNC lathe or milling machines and can be easily moved from one machine to another as needed for production. This way, it can assist with the work where it is needed.
HALTER LOADASSISTANT VIDEOS
HALTER gépek működés közben
Add some content for each one of your videos, like a description, transcript or external links.To add, remove or edit tab names, go to Tabs.
HALTER LOADASSISTANT
UNIVERSAL SERIES
UNIVERSAL
Compact 12
- Turning and milling
- Min. and max. Workpiece size (LxW): 10x10 mm and 135x135 mm
- Workpiece diameter: 10 - 135 mm
- Max. robotic arm load 12 kg
- Grid plates
UNIVERSAL
Premium 20/35
- Turning and milling
- Min. and max. Workpiece size (LxW): 10x10 mm és 270x270 mm
- Workpiece diameter: 10 - 270 mm
- Max. Robotic arm load 20/35 kg
- Grid plates
UNIVERSAL
Big 35/70
- Turning and milling
- Min. and max. Workpiece size (LxW): 10x10 mm és 300x300 mm
- Workpiece diameter: 10 - 300 mm
- Max. Robotic arm load 35/70 kg
- Grid plates
TURNSTACKER SERIES
TURNSTACKER
Compact 12
- Turning
- Workpiece rotator for double-sided machining
- Workpiece diameter: 25 - 135 mm
- Max. robotic arm load 12 kg
- Loading system
TURNSTACKER
Premium 20/35
- Turning
- Workpiece rotator for double-sided machining
- Workpiece diameter: 43 - 230 mm
- Max. Robotic arm load 20/35 kg
- Loading system
TURNSTACKER
Big 35/70
- Turning
- Workpiece rotator for double-sided machining
- Workpiece diameter: 43 - 300 mm
- Max. Robotic arm load 35/70 kg
- Loading system
MILLSTACKER SERIES
MILLSTACKER
Compact 12
- Milling
- Min. and max. Workpiece size (LxW): 25x25 mm és 125x125 mm
- Max. Robotic arm load 12 kg
- Loading system
MILLSTACKER
Premium 20/35
- Milling
- Min. and max. Workpiece size (LxW): 40x40 mm és 180x180 mm
- Max. Robotic arm load 20/35 kg
- Loading system
MILLSTACKER
Big 35/70
- Milling
- Min. and max. Workpiece size (LxW): 40x40 mm és 250x250 mm
- Max. Robotic arm load 35/70 kg
- Loading system
CNC ACCESSORIES
Automatic servo door opening system
These door opening systems have been developed to automatically open and close the door of the CNC machine. The servo-controlled door opening systems are made with their own electrical cabinet, controlled by Siemens. Self-learning and automatically detects resistance, making it 100% safe to use.
The automatic door opener helps reduce the physical strain on operators working on the CNC machine.
- Easy to install
- Compatible with any CNC machine
- Short delivery time
